MiNi PC K6-F17H-14125

CPU Intel Celeron J4125 2.0GHz-2.7GHz
Cores/Thread 4 Cores / 4 Threads
Cache 4 MB
TDP 10W z
Architecture Gemini Lake

Memory 1*SO-DIMM DDR4 slot, max support 16GB
Storage SSD (M.2)
Optional HDD (supports expansion of a 2.5-inch hard drive)
Audio Card HD Audio realtek ALC 662 Extendable OS
Graphics Intel UHD Graphics 600
Network 10/100/1000Mbps Adaptive, intel I225
Extendable WIFI+Bluetooth Module(MPCIE)or 3G/4G Module( SIM card slot on the motherboard)
OS Support Windows 10/Windows 11/ Linux

I/O Ports 4*USB3.0、2*USB2.0、1*DP、2*HDMI、2*RJ45、1*DC、1*MIC-IN、1*LINE-OUT、1*TYPE-C、 1*CLS、2~4*RS232 COM

Internal I/O Ports 1*COM1-2 Pin、1*COM3-4 PIN、1*CPU-FAN、1*JP1 Pin、1*FP AUDIO Pin、1*JP3 Pin、1*TPM Pin、1*GPIO Pin、1*BAT_CON(Battery)、1*Power Switch indicator Pin

Display Mode 4K/ Support Triple display (Duplicate mode, Extend mode)

Max Resolution(DP): 4096x2160@60Hz; Max Resolution(HDMI): 4096*2160@30Hz

Boot Mode PXE / Auto-power-on / Wake-on-LAN

Intel Virtualization Support VT-x，Support VT-d

Intel Hyper-Threading Not Support

Working Environment Temperature:-10~60 ℃

Relative Humidity：0~95% (No Condensation)

Working Voltage DC 12V - 3A Static Electricity Contact discharge 2K, Air discharge 6K

Storage Environment Temperature：-10~60 ℃

Relative Humidity：0~95% (No Condensation)

Warranty 1 year (Carry-in)
