GT1400-i7-1165G7

ร้านค้า / Industrial Computer

รายละเอียดสินค้า

Industrial PC: GT Series

Brand: ENTGROUP

CPU : Onboard 11th Gen 10nm CPU Comet Lake Intel Core i7-1165G7 4 cores 8 threads 2.8GHz up to 4.7GHz 12MB cache TDP 12W Intel Iris Xe Graphics
TDP : Refer to the above CPU
Chipset : SOC
Memory : J4125/J6412: 1 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB 8th/10th/11th: 2 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB/64GB
OS : Windows 10, Windows 11, WES 10, Linux
Audio : Intel high definition audio controller
Network : 2 x Intel(R) i225V Gigabit Network Connection 10/100Mbps/1000Mbps BaseT LAN
Video : Refer to the above CPU

Storage
M.2 : 1 x M.2 slot for SATA 2242/2260/2280 SSD
M.2 : 1 x M.2 slot for SATA/NVME 2280 SSD
SATA : 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s

Wi-Fi
Module : 1 x M.2 2230 slot for Wi-Fi & Bluetooth module 1 x M.2 3042/3052 slot for 3G/4G/5G/Wi-Fi module
Antenna : 5 x inner RF cables and 5 x external antennas

Input/output port
Switch : 1 x Power On/Off Switch
Power : 1 x 4pin phoenix terminal power supply input, support 9~36V
EXT IO : 1 x Integrated 4-way 3-wire COM, 10-way GPIO, 1 x Remote Switch
COM : 2 x RS232/RS422/RS485 COM, 4 x Expanded RS232 COM
USB : J4125/J6412: 4 x USB3.0, 2 x USB2.0, 8th/10th/11th: 2 x USB3.0, 4 x USB2.0
ATX : 1 x ATX
Display : 1 x HDMI 1.4
LAN : 2 x RJ45 Intel 2.5G LAN(support four extended network ports)
SIM : 1 x embedded SIM card slot onboard
Audio : 1 x MIC, 1 x SPK

Power and Working Environment

Input : DC100-240V AC/50-60Hz

Output : 9V~36V

Operating Temperature : -20°C/+60°C Centigrade

Storage Temperature : -30/+70 Centigrade

Relative Humidity : 10%~90%@30°C(non-condensing)

Product Dimension & Details

Functions : AWAL, Wake On LAN, RTC, Watchdog

Size : Net 2kg, Gross 2.5kg
Shell : Black color aluminum alloy(any customized color for bulk order)

Warranty 1 Year (Carry-in)
