GT1300-i5-10200H

CPU : Onboard Intel Comet Lake 14nm CPU Intel Core i5-10200H 2.4GHz Max 4.1GHz (Turbo boost Technology) Four Cores Eight Threads 8MB cache TDP 45W Intel® UHD Graphics.
TDP : Refer to the above CPU
Chipset : SOC
Memory : 2 x SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB/64GB
OS : Windows 10, Windows 11, WES 10, Linux
Audio : Intel high definition audio controller
Network : 2 x Intel(R) i225V Gigabit Network Connection 10/100Mbps/1000Mbps BaseT LAN
Video : Refer to the above CPU

Storage
Msata : 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s
SSD : 1 x M.2 slot for NVME 2280 SSD
SATA : 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s

Wi-Fi
Module : 1 x mini PCIE-full/mini PCIE-half port for Wi-Fi/Bluetooth module , 1 x mini PCIE-half/full port for 3G/4G module
Antenna : 2 x inner RF cables and 2 x external antennas

Input/output port
Switch : 1 x Power On/Off Switch
Power : 1 x 3pin phoenix terminal power supply input, support 9~36V
Buttom : 1 x ATX/AT quick switch
COM : 6 x DB9 COM(2xCOM support RS232/RS422/RS485)
USB : 4 x USB2.0, 2 x USB3.0
GPIO : 1 x GPIO( 7pin input, 7pin output)
Display : 3 x HDMI 1.4
LAN : 2 x RJ45 Intel 2.5G LAN
4G Module : 1 x mini PCIE-full port for 3G/4G module
SIM : 1 x embedded SIM card slot onboard
Audio : 1 x MIC, 1 x SPK
Others : 1 x CMOS clear button, 1 x 2pin phoenix terminal power supply input

Power and Working Environment

Input : DC100-240V AC/50-60Hz

Output : 9V~36V

Operating Temperature : -20°C/+60°C Centigrade

Storage Temperature : -30/+70 Centigrade

Relative Humidity : 10%~90%@30°C(non-condensing)

Product Dimension & Details

Functions : AWAL, Wake On LAN, RTC, Watchdog
