GT1200-i7-4578U

ร้านค้า / Industrial Computer

รายละเอียดสินค้า

Industrial PC: GT Series

Brand: ENTGROUP

CPU : Onboard Intel Haswell 22nm CPU Intel Core i7-4578U 3.0GHz Max 3.5GHz (Turbo boost Technology) Dual Cores Four Threads 4MB cache TDP 28W Intel® Iris® Graphics 5100.
TDP : 28W
Chipset : Intel Sunrise Point-LP, Intel Skylake-U
Memory : 4th: 1 x SO-DIMM DDR3L Slot, Support 4GB/8GB 6th/7th/8th: 1 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB 8th/10th: 2 x SO-DIMM DDR4 Slot, Support 4GB/8GB/16GB/32GB/64GB
OS : Windows 7/Windows 8/Windows 10/Linux
Audio : Intel High Definition Audio and USB Audio and HID
Network : 2 x Onboard Realtek RTL8111 Gigabit Ethernet NIC 10/100Mbps/1000Mbps BaseT LAN
Video : Refer to the above CPU

Storage
SSD : 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s 6th/7th/8th/10th: 1 x M.2 slot for NVME/NGFF 2280 SSD
Antenna : 2 x inner RF cables and 2 x external antennas

Input/output port

Switch : 1 x Power On/Kī^ǁŝƚĐŚ

Power : 1 x 12V-19V DC In

COM : 2 x DB9 RS232 COM

USB : 4 x USB2.0, 4 x USB3.0

Display : 1 x VGA, 1 x HDMI 1.4

LAN : 2 x RJ45 Giga LAN

4G Module : 1 x mini PCIE-full port for 3G/4G module

SIM : 1 x embedded SIM card slot onboard

Audio : 1 x MIC, 1 x SPK

Power and Working Environment

Input : DC100-240V AC/50-60Hz

Output : DC+12V~+19V, recommend 12V/5A

Operating Temperature : -20°C/+60°C Centigrade

Storage Temperature : -30/+70 Centigrade

Relative Humidity : 10%~90%@30°C(non-condensing)

Product Dimension & Details

Functions : AWAL, Wake On LAN, RTC, Watchdog

Size: 193.9*127*57.2mm

Mounting : 4 Mounting holes on case
Cooling Mode : Fanless

Warranty 1 Year (Carry-in)
